Webinar: Linking Injection Molding and Nonlinear FEA of Plastic Parts with Moldex3D Digimat-RP

in Past Events on 03/02/2016
A- A A+
Share
  • Date：May 06, 2016
  • Location： 2:30 PM EDT



Webinar: Integrating Draping and Compression Molding Processes



2:30-3:00 PM EDT | May 6, 2016

The continuous surge in demand for lightweight yet high-strength design has prompted large components to undergo composite-for-metal replacement. One of the most common processes for making composite products is a two-step process – draping followed by compression molding of the draped part . With this process, the challenge is how to effectively control the deformed shape of the final part. In this webinar, we will show you how to obtain the effects of draping on fiber orientation through LS-DYNA structural analysis software, and then export the effects into Moldex3D for an integrated analysis. Such an analysis can help engineers evaluate the effects of draping on warpage for the best possible design.





*This session will also be offered on June 22, 2016, 10:30 AM CET/ 2:00 PM IST.





Registration



Session is over. Watch our on-demand webinars.
